Stainless Steel Jacketed Tank, Capacity: 11,000Lt
Availability: In Stock
Item No: 5506
Brand:
Model:
Unit is a heavy-walled stainless jacketed storage tank. Capacity: 11,000Lt. Dimension: 1900mm Dia x 3700mm H x 1200mm H Cone. The tank has a dished top with a hinged top manway. Centre-mounted C.I.P spray ball. Tank is jacketed on straight-wall & cone. Steep conical bottom with 75mm dia discharge. The vessel has been sprayed with foam insulation. The tank was previously used as a fermentation vessel. Overall Height: 6600mm.
